JAZO EDGE-X ALU HS-42R

Description:

The JAZO EDGE-X HS-42R aluminium ventilation grille with clamp bracket mounting or screw-in anchor consists of a border with an extrusion profile, single horizontal blades (louvres) and a drip sill. The size of the safety grille is configurable and has a net passage of 42%.

Each blade is welded at the front and/or back, creating a single metallic whole. This meets the requirements for the earthing of technical spaces and one earth wire is sufficient. The installation depth is 75mm and fasteners are included. There are various types of edging profiles and mounting frames for a variety of installation options. This makes installation in any construction detail possible.

Aluminium safety ventilation grilles High Safety are specially designed for natural ventilation of transformer rooms and gas rooms. This provides optimum protection for people, animals, equipment and machines.

Specifications:

• Rainproof
• Snow and dust resistant
• Sand-resistant
• Pierce-proof
• Flame retardant
• Mouse-proof
• Maintenance free
• One metallic unit for grounding
• Vandal-proof and condensation-draining

Surface treatment:

Provided with a sustainable environmentally friendly pre-treatment. Powder coating in RAL colour of your choice.

Do you need specific advice regarding access and shielding of technical rooms? Feel free to contact us without obligation. You can also contact us for all your ventilation calculations.
